import pandas as pd
import numpy as np
#--------------
from sklearn import feature_selection
from sklearn.compose import make_column_transformer
from sklearn.preprocessing import LabelEncoder, OneHotEncoder, OrdinalEncoder
from sklearn.preprocessing import MinMaxScaler, StandardScaler, RobustScaler
from imblearn.over_sampling import RandomOverSampler
#------------
from sklearn.model_selection import train_test_split, GridSearchCV, cross_validate
from sklearn.model_selection import cross_val_score, StratifiedShuffleSplit, KFold
from sklearn.linear_model import LogisticRegression, LinearRegression
from sklearn.linear_model import SGDClassifier, RANSACRegressor, SGDRegressor
from sklearn.pipeline import Pipeline
from sklearn.ensemble import RandomForestClassifier, GradientBoostingClassifier, VotingRegressor
from sklearn.ensemble import AdaBoostClassifier, ExtraTreesClassifier, RandomForestRegressor
from sklearn.tree import DecisionTreeClassifier, DecisionTreeRegressor
from sklearn.neighbors import KNeighborsClassifier
from sklearn.svm import SVC, SVR
#-------------
import seaborn as sns
import matplotlib.pyplot as plt
import plotly.express as px
import plotly.graph_objects as go
from plotly.subplots import make_subplots
#-----------
np.set_printoptions(suppress=True)
pd.options.display.float_format = '{:,.2f}'.format
#---------------
from sklearn.decomposition import PCA
from sklearn.cluster import KMeans, DBSCAN
from sklearn.mixture import GaussianMixture, BayesianGaussianMixture
from sklearn.manifold import LocallyLinearEmbedding, TSNE,Isomap, MDS
from sklearn.metrics import homogeneity_score, silhouette_score, mean_squared_error
from sklearn.metrics import accuracy_score, confusion_matrix, classification_report
from sklearn.discriminant_analysis import LinearDiscriminantAnalysis
from scipy.stats import multivariate_normal
The source of the data is the paper called Dataset for estimation of obesity levels based on eating habits and physical condition in individuals from Colombia, Peru and Mexico by Fabio Mendoza Palechor and Alexis de la Hoz Manotas from the Universidad de la Costa, CUC in Colombia, published in Elsevier journal and sourced from the UCI website. The paper presents data for the estimation of obesity levels of individuals from the countries of Mexico, Peru and Colombia, based on their eating habits and physical condition. The data contains 17 attributes and 2111 records, the records are labeled with the class variable NObesity (Obesity Level), that allows classification of the data using the values of Insufficient Weight, Normal Weight, Overweight Level I, Overweight Level II, Obesity Type I, Obesity Type II and Obesity Type III. To balance the dataset 77% of the data was generated synthetically using the Weka tool and the SMOTE filter, 23% of the data was collected directly from users through a web platform.
data=pd.read_csv('ObesityDataSet_raw_and_data_sinthetic.csv')
# data=pd.read_csv('ObesityDataSet.csv')
data.head()
| Gender | Age | Height | Weight | family_history_with_overweight | FAVC | FCVC | NCP | CAEC | SMOKE | CH2O | SCC | FAF | TUE | CALC | MTRANS | NObeyesdad | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0 | Female | 21.00 | 1.62 | 64.00 | yes | no | 2.00 | 3.00 | Sometimes | no | 2.00 | no | 0.00 | 1.00 | no | Public_Transportation | Normal_Weight |
| 1 | Female | 21.00 | 1.52 | 56.00 | yes | no | 3.00 | 3.00 | Sometimes | yes | 3.00 | yes | 3.00 | 0.00 | Sometimes | Public_Transportation | Normal_Weight |
| 2 | Male | 23.00 | 1.80 | 77.00 | yes | no | 2.00 | 3.00 | Sometimes | no | 2.00 | no | 2.00 | 1.00 | Frequently | Public_Transportation | Normal_Weight |
| 3 | Male | 27.00 | 1.80 | 87.00 | no | no | 3.00 | 3.00 | Sometimes | no | 2.00 | no | 2.00 | 0.00 | Frequently | Walking | Overweight_Level_I |
| 4 | Male | 22.00 | 1.78 | 89.80 | no | no | 2.00 | 1.00 | Sometimes | no | 2.00 | no | 0.00 | 0.00 | Sometimes | Public_Transportation | Overweight_Level_II |
data.info()
<class 'pandas.core.frame.DataFrame'> RangeIndex: 2111 entries, 0 to 2110 Data columns (total 17 columns): # Column Non-Null Count Dtype --- ------ -------------- ----- 0 Gender 2111 non-null object 1 Age 2111 non-null float64 2 Height 2111 non-null float64 3 Weight 2111 non-null float64 4 family_history_with_overweight 2111 non-null object 5 FAVC 2111 non-null object 6 FCVC 2111 non-null float64 7 NCP 2111 non-null float64 8 CAEC 2111 non-null object 9 SMOKE 2111 non-null object 10 CH2O 2111 non-null float64 11 SCC 2111 non-null object 12 FAF 2111 non-null float64 13 TUE 2111 non-null float64 14 CALC 2111 non-null object 15 MTRANS 2111 non-null object 16 NObeyesdad 2111 non-null object dtypes: float64(8), object(9) memory usage: 280.5+ KB
Attributes related with eating habbits
The attributes related with the physicalcondition are:
other variables obtained were:
data['BMI'] = data.Weight/ data.Height**2 #----------------------ADDED
data.rename(columns={'family_history_with_overweight': 'FHO'}, inplace=True) #--------------ADDED
data.head(5)
| Gender | Age | Height | Weight | FHO | FAVC | FCVC | NCP | CAEC | SMOKE | CH2O | SCC | FAF | TUE | CALC | MTRANS | NObeyesdad | BMI | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0 | Female | 21.00 | 1.62 | 64.00 | yes | no | 2.00 | 3.00 | Sometimes | no | 2.00 | no | 0.00 | 1.00 | no | Public_Transportation | Normal_Weight | 24.39 |
| 1 | Female | 21.00 | 1.52 | 56.00 | yes | no | 3.00 | 3.00 | Sometimes | yes | 3.00 | yes | 3.00 | 0.00 | Sometimes | Public_Transportation | Normal_Weight | 24.24 |
| 2 | Male | 23.00 | 1.80 | 77.00 | yes | no | 2.00 | 3.00 | Sometimes | no | 2.00 | no | 2.00 | 1.00 | Frequently | Public_Transportation | Normal_Weight | 23.77 |
| 3 | Male | 27.00 | 1.80 | 87.00 | no | no | 3.00 | 3.00 | Sometimes | no | 2.00 | no | 2.00 | 0.00 | Frequently | Walking | Overweight_Level_I | 26.85 |
| 4 | Male | 22.00 | 1.78 | 89.80 | no | no | 2.00 | 1.00 | Sometimes | no | 2.00 | no | 0.00 | 0.00 | Sometimes | Public_Transportation | Overweight_Level_II | 28.34 |
data.describe() # BMI --> need dataframe of all continuous variables include BMI
| Age | Height | Weight | FCVC | NCP | CH2O | FAF | TUE | BMI | |
|---|---|---|---|---|---|---|---|---|---|
| count | 2,111.00 | 2,111.00 | 2,111.00 | 2,111.00 | 2,111.00 | 2,111.00 | 2,111.00 | 2,111.00 | 2,111.00 |
| mean | 24.31 | 1.70 | 86.59 | 2.42 | 2.69 | 2.01 | 1.01 | 0.66 | 29.70 |
| std | 6.35 | 0.09 | 26.19 | 0.53 | 0.78 | 0.61 | 0.85 | 0.61 | 8.01 |
| min | 14.00 | 1.45 | 39.00 | 1.00 | 1.00 | 1.00 | 0.00 | 0.00 | 13.00 |
| 25% | 19.95 | 1.63 | 65.47 | 2.00 | 2.66 | 1.58 | 0.12 | 0.00 | 24.33 |
| 50% | 22.78 | 1.70 | 83.00 | 2.39 | 3.00 | 2.00 | 1.00 | 0.63 | 28.72 |
| 75% | 26.00 | 1.77 | 107.43 | 3.00 | 3.00 | 2.48 | 1.67 | 1.00 | 36.02 |
| max | 61.00 | 1.98 | 173.00 | 3.00 | 4.00 | 3.00 | 3.00 | 2.00 | 50.81 |
data.describe(include=['O'])
| Gender | FHO | FAVC | CAEC | SMOKE | SCC | CALC | MTRANS | NObeyesdad | |
|---|---|---|---|---|---|---|---|---|---|
| count | 2111 | 2111 | 2111 | 2111 | 2111 | 2111 | 2111 | 2111 | 2111 |
| unique | 2 | 2 | 2 | 4 | 2 | 2 | 4 | 5 | 7 |
| top | Male | yes | yes | Sometimes | no | no | Sometimes | Public_Transportation | Obesity_Type_I |
| freq | 1068 | 1726 | 1866 | 1765 | 2067 | 2015 | 1401 | 1580 | 351 |
fig = make_subplots(rows=4, cols=2,
subplot_titles=("Family history with over-weight",
"Smoke",
"Comsumption of high caloric food",
"Consumption of alcohol",
"Calories consumption monitoring",
"Transportation used",
"Consumption of food between meals",
"Gender"))
fig.add_trace(go.Bar(x =data['FHO'].value_counts().index.tolist(),
y = data['FHO'].value_counts().values.tolist()), row=1, col=1)
fig.add_trace(go.Bar(x=data['SMOKE'].value_counts().index.tolist(),
y=data['SMOKE'].value_counts().values.tolist()),row=1, col=2)
fig.add_trace(go.Bar(x=data['FAVC'].value_counts().index.tolist(),
y=data['FAVC'].value_counts().values.tolist()),row=2, col=1)
fig.add_trace(go.Bar(x=data['CALC'].value_counts().index.tolist(),
y=data['CALC'].value_counts().values.tolist()),row=2, col=2)
fig.add_trace(go.Bar(x=data['SCC'].value_counts().index.tolist(),
y=data['SCC'].value_counts().values.tolist()),row=3, col=1)
fig.add_trace(go.Bar(x=data['MTRANS'].value_counts().index.tolist(),
y=data['MTRANS'].value_counts().values.tolist()),row=3, col=2)
fig.add_trace(go.Bar(x=data['CAEC'].value_counts().index.tolist(),
y=data['CAEC'].value_counts().values.tolist()),row=4, col=1)
fig.add_trace(go.Bar(x=data['Gender'].value_counts().index.tolist(),
y=data['Gender'].value_counts().values.tolist()),row=4, col=2)
fig.update_layout(height=1000, width=800,showlegend=False, title_text="Categorical features")
fig.show()
fig, ax = plt.subplots(nrows = 3, ncols = 2, figsize=(20, 10))
ax[0,0].hist(data.FCVC)
ax[0,0].set_title('Frequency of consumption of vegetables')
ax[0,1].hist(data.TUE)
ax[0,1].set_title('Time using technology devices ')
ax[1,0].hist(data.NCP)
ax[1,0].set_title('Number of main meals ')
ax[1,1].hist(data.CH2O)
ax[1,1].set_title('Consumption of water daily')
ax[2,0].hist(data.Age)
ax[2,0].set_title('Age')
ax[2,1].hist(data.BMI)
ax[2,1].set_title('BMI')
plt.show()
# FHO x BMI x gender
fig = px.box(data, x="FHO", y="BMI", facet_col="Gender", color="Gender", boxmode="overlay",
title="BMI distribution based on Family history with overweight by Gender",
points='outliers', labels={"FHO":"Family history with overweight"})
fig.add_hline(y=18.5, line_dash="dot", annotation_text="Underweight", annotation_position="bottom")
fig.add_hline(y=24.9, line_dash="dot", annotation_text="Normal", annotation_position="bottom")
fig.add_hline(y=29.9, line_dash="dot", annotation_text="Overweight", annotation_position="bottom")
fig.add_hline(y=29.9, line_dash="dot", annotation_text="Obesity", annotation_position="top")
# Age x NObeyesdad x gender
fig2 = px.box(data, x="NObeyesdad", y="Age", facet_col="Gender", color="Gender",
title="Age distribution across Obesity classes by Gender",
boxmode="overlay", points='outliers', labels={"NObeyesdad":"Obesity level"},
category_orders={"NObeyesdad":["Insufficient_Weight", "Normal_Weight",
"Overweight_Level_I", "Overweight_Level_II",
"Obesity_Type_I", "Obesity_Type_II", "Obesity_Type_III"]})
# MTRANS x Age x gender
fig3 = px.box(data, x="MTRANS", y="Age", facet_col="Gender", color="Gender",
title="Age distribution across Transportation categories by Gender",
boxmode="overlay", points='outliers', labels={"MTRANS":"Transportation used"})
# CAEC x FCVC x FHO
fig4 = px.box(data, x="CAEC", y="FCVC", facet_col="Gender", color="Gender",
boxmode="overlay", points='outliers',
title="Consuption of vegetables distribution across Food between meals classes by Gender",
category_orders={"CAEC":["no", "Sometimes", "Frequently", "Always"]},
labels={"FCVC":"Frequency of consumption of vegetables",
"CAEC":"Consumption of food between meals"})
fig.show()
fig2.show()
fig3.show()
fig4.show()
Chart 1:
Chart 2:
Chart 3:
Chart 4:
px.bar(data['NObeyesdad'].value_counts(), color = data['NObeyesdad'].value_counts().values, title = 'Obesity level')
Based on the short brief of data information,the categories of obesity levels were unbalanced in the original dataset. And, this presented a learning problem for the data mining methods, since it would learn to identify correctly the category with most records compared with the categories with less data. After the balancing class problem was identified, synthetic data was generated, up to 77% of the data, using the tool Weka and the filter SMOTE.
data1 = data[['Gender', 'FHO', 'FAVC', 'SMOKE', 'SCC']].apply(LabelEncoder().fit_transform)
data2 = pd.get_dummies(data.MTRANS,drop_first=True)
data2.info()
<class 'pandas.core.frame.DataFrame'> RangeIndex: 2111 entries, 0 to 2110 Data columns (total 4 columns): # Column Non-Null Count Dtype --- ------ -------------- ----- 0 Bike 2111 non-null uint8 1 Motorbike 2111 non-null uint8 2 Public_Transportation 2111 non-null uint8 3 Walking 2111 non-null uint8 dtypes: uint8(4) memory usage: 8.4 KB
data['CALC'].unique()
array(['no', 'Sometimes', 'Frequently', 'Always'], dtype=object)
# check back the number label vs text categories
data1['NObeyesdad']=data['NObeyesdad'].map({'Insufficient_Weight':0,'Normal_Weight':1,'Overweight_Level_I':2,'Overweight_Level_II':3,
'Obesity_Type_I':4,'Obesity_Type_II':5,
'Obesity_Type_III':6})
data1['CAEC']=data['CAEC'].map({'Sometimes':1, 'Frequently':2, 'Always':3, 'no':0})
data1['CALC']=data['CALC'].map({'Sometimes':1, 'Frequently':2, 'Always':3, 'no':0})
data3=data.iloc[:,[6,7,10,12,13,17]].round().astype('int32')
data_total=pd.concat([data.iloc[:,[1,2,3]],data3,data1, data2],axis=1)
data_total.info()
<class 'pandas.core.frame.DataFrame'> RangeIndex: 2111 entries, 0 to 2110 Data columns (total 21 columns): # Column Non-Null Count Dtype --- ------ -------------- ----- 0 Age 2111 non-null float64 1 Height 2111 non-null float64 2 Weight 2111 non-null float64 3 FCVC 2111 non-null int32 4 NCP 2111 non-null int32 5 CH2O 2111 non-null int32 6 FAF 2111 non-null int32 7 TUE 2111 non-null int32 8 BMI 2111 non-null int32 9 Gender 2111 non-null int64 10 FHO 2111 non-null int64 11 FAVC 2111 non-null int64 12 SMOKE 2111 non-null int64 13 SCC 2111 non-null int64 14 NObeyesdad 2111 non-null int64 15 CAEC 2111 non-null int64 16 CALC 2111 non-null int64 17 Bike 2111 non-null uint8 18 Motorbike 2111 non-null uint8 19 Public_Transportation 2111 non-null uint8 20 Walking 2111 non-null uint8 dtypes: float64(3), int32(6), int64(8), uint8(4) memory usage: 239.3 KB
data_total.columns
Index(['Age', 'Height', 'Weight', 'FCVC', 'NCP', 'CH2O', 'FAF', 'TUE', 'BMI',
'Gender', 'FHO', 'FAVC', 'SMOKE', 'SCC', 'NObeyesdad', 'CAEC', 'CALC',
'Bike', 'Motorbike', 'Public_Transportation', 'Walking'],
dtype='object')
data_total.columns=['Age', 'Height', 'Weight', 'Vege', 'Meals', 'Water', 'Physical_act', 'Technology', 'BMI',
'Gender', 'Family_his', 'Calo_food', 'Smoke', 'Mon_cal', 'Obesity', 'Snack', 'Alko',
'Bike', 'Motorbike', 'Public_trans', 'Walking']
data_total.head()
| Age | Height | Weight | Vege | Meals | Water | Physical_act | Technology | BMI | Gender | ... | Calo_food | Smoke | Mon_cal | Obesity | Snack | Alko | Bike | Motorbike | Public_trans | Walking | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0 | 21.00 | 1.62 | 64.00 | 2 | 3 | 2 | 0 | 1 | 24 | 0 | ... | 0 | 0 | 0 | 1 | 1 | 0 | 0 | 0 | 1 | 0 |
| 1 | 21.00 | 1.52 | 56.00 | 3 | 3 | 3 | 3 | 0 | 24 | 0 | ... | 0 | 1 | 1 | 1 | 1 | 1 | 0 | 0 | 1 | 0 |
| 2 | 23.00 | 1.80 | 77.00 | 2 | 3 | 2 | 2 | 1 | 24 | 1 | ... | 0 | 0 | 0 | 1 | 1 | 2 | 0 | 0 | 1 | 0 |
| 3 | 27.00 | 1.80 | 87.00 | 3 | 3 | 2 | 2 | 0 | 27 | 1 | ... | 0 | 0 | 0 | 2 | 1 | 2 | 0 | 0 | 0 | 1 |
| 4 | 22.00 | 1.78 | 89.80 | 2 | 1 | 2 | 0 | 0 | 28 | 1 | ... | 0 | 0 | 0 | 3 | 1 | 1 | 0 | 0 | 1 | 0 |
5 rows × 21 columns
px.box(data_total, x = 'Meals', y = 'Age', facet_col = 'Gender', title = 'Number of main meals')
px.box(data_total, x = 'Water', y = 'Age', facet_col = 'Gender', title = 'Consumption of water daily')
px.box(data_total, x = 'Vege', y = 'Age', facet_col = 'Gender', title = 'Consumption of vegetable')
px.box(data_total, x = 'Technology', y = 'Age', facet_col = 'Gender', title = 'Time using technology devices')
After converting the columns with float numbers into categorical variables, we use box plot to detect the outliers and see the connection between those variables with age and gender. The Gender value 0 represents Female and value 1 is Male.
corr = data_total.drop(['Height','Weight'], axis=1).corr()
corr.style.background_gradient(cmap='coolwarm').set_precision(1)
| Age | Vege | Meals | Water | Physical_act | Technology | BMI | Gender | Family_his | Calo_food | Smoke | Mon_cal | Obesity | Snack | Alko | Bike | Motorbike | Public_trans | Walking | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Age | 1.0 | 0.0 | -0.0 | -0.0 | -0.1 | -0.3 | 0.2 | 0.0 | 0.2 | 0.1 | 0.1 | -0.1 | 0.3 | -0.1 | 0.0 | 0.0 | 0.0 | -0.6 | -0.1 |
| Vege | 0.0 | 1.0 | 0.0 | 0.1 | 0.0 | -0.1 | 0.2 | -0.3 | 0.0 | -0.0 | 0.0 | 0.1 | 0.2 | 0.1 | 0.0 | -0.0 | -0.0 | 0.1 | 0.0 |
| Meals | -0.0 | 0.0 | 1.0 | 0.1 | 0.1 | 0.0 | 0.0 | 0.1 | 0.1 | -0.0 | 0.0 | -0.0 | 0.0 | 0.1 | 0.1 | 0.0 | 0.0 | -0.1 | 0.0 |
| Water | -0.0 | 0.1 | 0.1 | 1.0 | 0.1 | -0.0 | 0.1 | 0.1 | 0.1 | 0.0 | -0.0 | -0.0 | 0.1 | -0.1 | 0.1 | 0.0 | -0.0 | 0.0 | 0.0 |
| Physical_act | -0.1 | 0.0 | 0.1 | 0.1 | 1.0 | 0.1 | -0.2 | 0.2 | -0.1 | -0.1 | 0.0 | 0.1 | -0.2 | 0.0 | -0.1 | 0.1 | -0.0 | -0.1 | 0.1 |
| Technology | -0.3 | -0.1 | 0.0 | -0.0 | 0.1 | 1.0 | -0.1 | 0.0 | 0.0 | 0.1 | 0.0 | -0.0 | -0.1 | 0.0 | -0.0 | -0.0 | -0.1 | 0.1 | 0.1 |
| BMI | 0.2 | 0.2 | 0.0 | 0.1 | -0.2 | -0.1 | 1.0 | -0.1 | 0.5 | 0.2 | -0.0 | -0.2 | 1.0 | -0.3 | 0.2 | -0.0 | -0.0 | 0.1 | -0.1 |
| Gender | 0.0 | -0.3 | 0.1 | 0.1 | 0.2 | 0.0 | -0.1 | 1.0 | 0.1 | 0.1 | 0.0 | -0.1 | -0.0 | -0.1 | -0.0 | 0.1 | 0.0 | -0.2 | 0.0 |
| Family_his | 0.2 | 0.0 | 0.1 | 0.1 | -0.1 | 0.0 | 0.5 | 0.1 | 1.0 | 0.2 | 0.0 | -0.2 | 0.5 | -0.2 | -0.0 | -0.0 | -0.1 | -0.1 | -0.1 |
| Calo_food | 0.1 | -0.0 | -0.0 | 0.0 | -0.1 | 0.1 | 0.2 | 0.1 | 0.2 | 1.0 | -0.1 | -0.2 | 0.2 | -0.2 | 0.1 | -0.1 | -0.0 | 0.0 | -0.2 |
| Smoke | 0.1 | 0.0 | 0.0 | -0.0 | 0.0 | 0.0 | -0.0 | 0.0 | 0.0 | -0.1 | 1.0 | 0.0 | 0.0 | 0.1 | 0.1 | -0.0 | 0.0 | -0.0 | 0.0 |
| Mon_cal | -0.1 | 0.1 | -0.0 | -0.0 | 0.1 | -0.0 | -0.2 | -0.1 | -0.2 | -0.2 | 0.0 | 1.0 | -0.2 | 0.1 | 0.0 | 0.0 | 0.0 | 0.0 | 0.0 |
| Obesity | 0.3 | 0.2 | 0.0 | 0.1 | -0.2 | -0.1 | 1.0 | -0.0 | 0.5 | 0.2 | 0.0 | -0.2 | 1.0 | -0.3 | 0.2 | -0.0 | -0.0 | 0.1 | -0.1 |
| Snack | -0.1 | 0.1 | 0.1 | -0.1 | 0.0 | 0.0 | -0.3 | -0.1 | -0.2 | -0.2 | 0.1 | 0.1 | -0.3 | 1.0 | -0.0 | 0.0 | 0.1 | -0.0 | 0.1 |
| Alko | 0.0 | 0.0 | 0.1 | 0.1 | -0.1 | -0.0 | 0.2 | -0.0 | -0.0 | 0.1 | 0.1 | 0.0 | 0.2 | -0.0 | 1.0 | -0.0 | -0.0 | 0.0 | -0.0 |
| Bike | 0.0 | -0.0 | 0.0 | 0.0 | 0.1 | -0.0 | -0.0 | 0.1 | -0.0 | -0.1 | -0.0 | 0.0 | -0.0 | 0.0 | -0.0 | 1.0 | -0.0 | -0.1 | -0.0 |
| Motorbike | 0.0 | -0.0 | 0.0 | -0.0 | -0.0 | -0.1 | -0.0 | 0.0 | -0.1 | -0.0 | 0.0 | 0.0 | -0.0 | 0.1 | -0.0 | -0.0 | 1.0 | -0.1 | -0.0 |
| Public_trans | -0.6 | 0.1 | -0.1 | 0.0 | -0.1 | 0.1 | 0.1 | -0.2 | -0.1 | 0.0 | -0.0 | 0.0 | 0.1 | -0.0 | 0.0 | -0.1 | -0.1 | 1.0 | -0.3 |
| Walking | -0.1 | 0.0 | 0.0 | 0.0 | 0.1 | 0.1 | -0.1 | 0.0 | -0.1 | -0.2 | 0.0 | 0.0 | -0.1 | 0.1 | -0.0 | -0.0 | -0.0 | -0.3 | 1.0 |
EXPLAIN:
Later we won't put Weight and Height in our model since these two variables fomulate BMI score basing on which we categorized Obesity level. We eliminate Weight and Height from our analysis.
Two variables: BMI and Obesity are the targets of our predictive models, we don't look into correlation between these ones.
We notice some pair of variables which correlation scores are around + or - 0.3, 0.4 or 0.5, hinder mild linear relationship:
We will continue to examine with p-value and VIF later.
Otherwise, risk of multi-colinearity is quite low (feature depends on another)
Link to theory interpretation: https://support.minitab.com/en-us/minitab-express/1/help-and-how-to/modeling-statistics/regression/how-to/correlation/interpret-the-results/
data_total.columns
Index(['Age', 'Height', 'Weight', 'Vege', 'Meals', 'Water', 'Physical_act',
'Technology', 'BMI', 'Gender', 'Family_his', 'Calo_food', 'Smoke',
'Mon_cal', 'Obesity', 'Snack', 'Alko', 'Bike', 'Motorbike',
'Public_trans', 'Walking'],
dtype='object')
sns.pairplot(data_total, diag_kind="kde")
<seaborn.axisgrid.PairGrid at 0x7fda577862d0>
EXPLAIN: obvious linear relationship between BMI and Weight, somewhat between Height and Weight.
X=data_total.drop(['BMI', 'Obesity','Height','Weight'], axis=1).values
Y_reg=data_total.BMI.values
Y_cls=data_total.Obesity.values
X_names=data_total.drop(['BMI', 'Obesity','Height','Weight'], axis=1).columns
X_names
Index(['Age', 'Vege', 'Meals', 'Water', 'Physical_act', 'Technology', 'Gender',
'Family_his', 'Calo_food', 'Smoke', 'Mon_cal', 'Snack', 'Alko', 'Bike',
'Motorbike', 'Public_trans', 'Walking'],
dtype='object')
def multicollinearity(model,features,feature_name):
from statsmodels.stats.outliers_influence import variance_inflation_factor
VIF=[variance_inflation_factor(features,i) for i in range(features.shape[1])]
for i,v in enumerate(VIF):
print(f"feature {feature_name[i]}: vif : {v}")
possible_multicollinearity=sum(map(lambda x: x>10,VIF))
Multicollinearity=sum([1 for vif in VIF if vif>100])
print(f"{possible_multicollinearity} case of possible multicollinearity")
print(f"{Multicollinearity} case of multicollinearity")
multicollinearity(LinearRegression(),X,X_names)
feature Age: vif : 16.31547976891398 feature Vege: vif : 17.60774806097755 feature Meals: vif : 11.569313517804954 feature Water: vif : 9.851687853218273 feature Physical_act: vif : 2.5384508457000803 feature Technology: vif : 2.111928603349352 feature Gender: vif : 2.316845228380526 feature Family_his: vif : 6.496189967592717 feature Calo_food: vif : 9.152568794907657 feature Smoke: vif : 1.0528683607611815 feature Mon_cal: vif : 1.1315249529074052 feature Snack: vif : 6.979445932433769 feature Alko: vif : 3.1870793446498955 feature Bike: vif : 1.0276099633308002 feature Motorbike: vif : 1.0422143899247462 feature Public_trans: vif : 5.240832061865968 feature Walking: vif : 1.1968608343117948 3 case of possible multicollinearity 0 case of multicollinearity
In line with corelation matrix, VIF high in Vege: Vege and Gender have high cor-coef score. However, correlation matrix shows low corelation between Gender and our targets (obesity, BMI), we can consider elimiminating Gender out of our model.
VIF high in Age: Vege and Public_trans have high cor-coef score. However, correlation matrix shows low corelation between Public_trans and our targets (obesity, BMI), we can consider elimiminating Public_trans out of our model.
There aren't many outliers nor the dataset appears to have a normal distribution, therefore we don't choose the Robust scaler nor the Standard scaler, respectively, for the regression models part of our project. The MinMax scaler will be used to scale the data for further processing.
Then we devide the scaled dataset into train and test data in the ratio of 80:20. This split will be necessary for future evaluation of the models' prediction accuracy.
# original shape of the dataset
X.shape
(2111, 17)
# using the MinMax scaler to scale and transform the original dataset
minmax = MinMaxScaler()
X_scaled = minmax.fit_transform(X)
X_scaled.shape
(2111, 17)
# splitting the scaled data and target for regression models into training and test data
# to keep the output of the functions stable we set the random_state=33 whenever applicable
# in the whole regression models section
X_train, X_test, y_train, y_test = train_test_split(X_scaled, Y_reg, train_size=0.8, random_state=33)
print(f'Shape of the train dataset: {X_train.shape}, {y_train.shape}')
print(f'Shape of the test dataset: {X_test.shape}, {y_test.shape}')
Shape of the train dataset: (1688, 17), (1688,) Shape of the test dataset: (423, 17), (423,)
We evaluate the models' performance in their default settings and clarify which of them perform the best on our dataset in general. Based on the results of the cross validation we select the best models to work on further and find the best performing algorithm and its setup for our dataset.
We pick the following algorithm for evaluation - linear regression, gradient descent, RANSAC, support vector machines, decision trees (with 3 various depths) and random forest.
# creating a list of picked algorithms
# the list includes tuples with the model name and the scikit learn algorithm
models = list()
models.append(("LinReg", LinearRegression()))
models.append(("SGD", SGDRegressor(random_state=33)))
models.append(("RANSAC", RANSACRegressor(random_state=33)))
models.append(("SVM", SVR()))
models.append(("DecisionTree_3", DecisionTreeRegressor(max_depth=3, random_state=33)))
models.append(("DecisionTree_6", DecisionTreeRegressor(max_depth=6, random_state=33)))
models.append(("DecisionTree_9", DecisionTreeRegressor(max_depth=9, random_state=33)))
models.append(("RandomForest", RandomForestRegressor(random_state=33)))
models
[('LinReg', LinearRegression()),
('SGD', SGDRegressor(random_state=33)),
('RANSAC', RANSACRegressor(random_state=33)),
('SVM', SVR()),
('DecisionTree_3', DecisionTreeRegressor(max_depth=3, random_state=33)),
('DecisionTree_6', DecisionTreeRegressor(max_depth=6, random_state=33)),
('DecisionTree_9', DecisionTreeRegressor(max_depth=9, random_state=33)),
('RandomForest', RandomForestRegressor(random_state=33))]
# running the cross validation on the scaled dataset for all the picked regression models
# the results saved into a dictionary for possible future analysis
# print the avg. score and standard deviation for each model
model_selection = dict()
for name, model in models:
model_name = name
model_scores = model_name + "_scores"
model_score_mean = model_name + "_score_mean"
model_score_std = model_name + "_score_std"
mod_scores = cross_val_score(model, X_scaled, Y_reg, cv=5)
mod_score_mean = round(mod_scores.mean(), 2)
mod_score_std = round(mod_scores.std(), 2)
model_selection[model_name] = {model_scores : mod_scores, model_score_mean : mod_score_mean,
model_score_std : mod_score_std}
print(f"Training set's avg. score with the {model_name} model: {mod_score_mean}")
print(f"The std. of the {model_name} model: {mod_score_std}\n")
Training set's avg. score with the LinReg model: -5.56 The std. of the LinReg model: 4.94 Training set's avg. score with the SGD model: -5.36 The std. of the SGD model: 4.78 Training set's avg. score with the RANSAC model: -6.59 The std. of the RANSAC model: 3.66 Training set's avg. score with the SVM model: -6.08 The std. of the SVM model: 5.44 Training set's avg. score with the DecisionTree_3 model: -5.52 The std. of the DecisionTree_3 model: 4.5 Training set's avg. score with the DecisionTree_6 model: -4.3 The std. of the DecisionTree_6 model: 3.65 Training set's avg. score with the DecisionTree_9 model: -2.96 The std. of the DecisionTree_9 model: 2.33 Training set's avg. score with the RandomForest model: -1.85 The std. of the RandomForest model: 1.84
To improve the performance of the SVM model we decrease the amount of feature for our model using the mutual information for regression function. This should be the most suitable option to capture the target dependency as we're handling non-linear data and continuous target values. We selected only features with dependency higher than 0.05 as we want to avoid keeping highly independent features which don't help us in the predictions' accuracy and slow down our algorithm.
# mutual information regression on the scaled dataset and regression target
mir = feature_selection.mutual_info_regression(X_scaled, Y_reg, random_state=33)
# the dependency values of the scaled dataset
mir
array([0.67619856, 0.15424088, 0.11480978, 0.08655001, 0.1340221 ,
0.1087864 , 0.17407366, 0.17733153, 0.03386696, 0. ,
0.02560416, 0.17951962, 0.09316461, 0. , 0.02689501,
0.05587618, 0.00609383])
# mutual information regression on the unscaled dataset and regression target
mir_unscaled = feature_selection.mutual_info_regression(X, Y_reg, random_state=33)
# the dependency values of the unscaled dataset
mir_unscaled
array([0.67250695, 0.17210171, 0.11970834, 0.08534248, 0.1340221 ,
0.1087864 , 0.17407366, 0.17733153, 0.03386696, 0. ,
0.02560416, 0.17951962, 0.09316461, 0. , 0.02689501,
0.05587618, 0.00609383])
We can see that there're a few (highly) independent values which we can remove in the following steps. Also the data scaling didn't actually have a major impact on the original dataset.
# print the amount of features that pass the 0.05 dependency threshold
# print the names of the selected features for the SVM model
print(f'Number of features above 0.05 threshold is {len(np.where(mir>=0.05)[0])} out of {len(mir)} total features.')
print(f'Name of selected features: {X_names[np.where(mir>=0.05)]}')
Number of features above 0.05 threshold is 11 out of 17 total features.
Name of selected features: Index(['Age', 'Vege', 'Meals', 'Water', 'Physical_act', 'Technology', 'Gender',
'Family_his', 'Snack', 'Alko', 'Public_trans'],
dtype='object')
# remove the features below mir 0.05
X_selected = X_scaled[:, np.where(mir>=0.05)[0]]
# confirm the change in the dataset shape
X_selected.shape
(2111, 11)
# split the dataset with selected features into train and test data at the 80:20 ratio
# split the target values into train and test too
X_sel_train, X_sel_test, y_sel_train, y_sel_test = train_test_split(X_selected, Y_reg, train_size=0.8, random_state=33)
# print the shape of the split data and targets
print(f'Shape of the train dataset: {X_sel_train.shape}, {y_sel_train.shape}')
print(f'Shape of the test dataset: {X_sel_test.shape}, {y_sel_test.shape}')
Shape of the train dataset: (1688, 11), (1688,) Shape of the test dataset: (423, 11), (423,)
In this section we tune the parameters for the earlier selected SVM, decision tree and random forest algorithms to find the best model for our data.
We use the GridSearch function to find the best parameter combination and compare the best score of the training data with the score on the test data to confirm the model isn't either underfitting or overfitting. We also use the MSE to improve our understanding of the models performance and ability to compare the result between all the evaluated models.
For the SVM model we selected various options of both the C and gamma parameters to find their best performing combination.
# create a dictionary of the parameter grid including the list of values 0.001, 0.01, 0.1, 1, 10, 100
# for both the C and gamma parameters
param_svm = {'C': [0.001, 0.01, 0.1, 1, 10, 100],
'gamma': [0.001, 0.01, 0.1, 1, 10, 100]}
# create the GridSearchCV model for the SVM algorithm
grid_search_svm = GridSearchCV(SVR(), param_grid=param_svm, cv=5, n_jobs=-1)
# fit the model to the train data with the selected features and target
grid_search_svm.fit(X_sel_train, y_sel_train)
# print the best score from the grid search, the model's score of the test data and best parameters combination
print(f"Best parameters: {grid_search_svm.best_params_}")
print(f"Best cross-validation score: {grid_search_svm.best_score_:.2f}")
print(f"Test set score: {grid_search_svm.score(X_sel_test, y_sel_test):.2f}")
# predict the target values of the test data and print the MSE of the prediction and the actual target values
y_pred = grid_search_svm.predict(X_sel_test)
print(f"MSE: {mean_squared_error(y_test, y_pred):.2f}")
Best parameters: {'C': 10, 'gamma': 10}
Best cross-validation score: 0.76
Test set score: 0.80
MSE: 12.41
Although we expect the random forest perform better the decision tree model will help us understand the importance of various features. It also performed better than the SVM model with the default setup so we can clarify whether it'll be the same case also after the parameter tuning or not.
# create a dictionary of the parameter grid for the max_depth and max_features parameters
param_dt = {'max_depth': [i for i in range(3,12,2)],
'max_features': [i for i in range(1, X_train.shape[1])]}
# create the GridSearchCV model for the Decision tree algorithm
grid_search_dt = GridSearchCV(DecisionTreeRegressor(random_state=33), param_grid=param_dt, cv=5, n_jobs=-1)
# fit the model to the train data with the selected features and target
grid_search_dt.fit(X_train, y_train)
# print the best score from the grid search, the model's score of the test data and best parameters combination
print(f"Best parameters: {grid_search_dt.best_params_}")
print(f"Best cross-validation score: {grid_search_dt.best_score_:.2f}")
print(f"Test score: {grid_search_dt.score(X_test, y_test):.2f}")
# predict the target values of the test data and print the MSE of the prediction and the actual target values
y_pred = grid_search_dt.predict(X_test)
print(f"MSE: {mean_squared_error(y_test, y_pred):.2f}")
Best parameters: {'max_depth': 11, 'max_features': 15}
Best cross-validation score: 0.74
Test score: 0.70
MSE: 18.50
# define a function for ploting the feature importance
def plot_feature_importance(model, x, name):
n_feature = x.shape[1]
print(n_feature)
plt.barh(range(n_feature), model.feature_importances_)
plt.yticks(np.arange(n_feature), name)
plt.xlabel("Feature importance")
plt.ylabel("Feature")
plt.title("Feature importance of Decision tree model")
# create and fit the decision tree algorithm on the training set using the best parameters from above
dt = DecisionTreeRegressor(max_depth=11, max_features=15, random_state=33)
dt.fit(X_train, y_train)
DecisionTreeRegressor(max_depth=11, max_features=15, random_state=33)
# plot the feature importance of the decision tree model
plot_feature_importance(dt, X, X_names)
17
The Decision tree tuning gave us the combination of max_depth=11 and max_features=15 as the most optimal, using almost the maximum values we allowed. The accuracy of the model on the training and test sets is 74% and 70%, respectively. The MSE of the Decision tree model is 18.50. We can conclude that the model is already performing worse than the SVM model while it's also slightly overfitting on the training model. Therefore there's no need to increase the maximum depth parameter even more which would improve the model accuracy most likely but increase the overfitting at the same time.
From the feature importance we see again that also for the Decision tree algorithm the Family history and Age are among the most relevant features in the prediction process.
Random forest was the best performing model in the default settings selection. In this part we try several options for its parameters n_estimators, max_depth and max_features using the GridSearch function again to see which combination gives us the best performance.
# create a dictionary of the parameter grid for the n_estimators, max_depth and max_features parameters
param_rf = {'n_estimators': [200,300,400,500],
'max_depth': [i for i in range(1,20,2)],
'max_features': [i for i in range(1, X_train.shape[1])]}
# create the GridSearchCV model for the Random forest algorithm
grid_search_rf = GridSearchCV(RandomForestRegressor(n_jobs=-1, random_state=33),
param_grid=param_rf, n_jobs=-1, cv=5)
# fit the model to the train data with the selected features and target
grid_search_rf.fit(X_train, y_train)
# print the best score from the grid search, the model's score of the test data and best parameters combination
print(f"Best parameters: {grid_search_rf.best_params_}")
print(f"Best cross-validation score: {grid_search_rf.best_score_:.2f}")
print(f"Test score: {grid_search_rf.score(X_test, y_test):.2f}")
# predict the target values of the test data and print the MSE of the prediction and the actual target values
y_pred = grid_search_rf.predict(X_test)
print(f"MSE: {mean_squared_error(y_test, y_pred):.2f}")
Best parameters: {'max_depth': 17, 'max_features': 5, 'n_estimators': 400}
Best cross-validation score: 0.86
Test score: 0.86
MSE: 8.80
X_train, X_test, y_train, y_test = train_test_split (X, Y_cls)
print(X_train.shape)
print(y_train.shape)
(1583, 17) (1583,)
classifiers = [
KNeighborsClassifier(n_neighbors = 5),
SVC(kernel="rbf", C=0.025, probability=True),
LogisticRegression(C=0.01, max_iter = 1000, penalty = 'l2',multi_class='ovr')]
scaler = MinMaxScaler()
for classifier in classifiers:
pipe = Pipeline(steps=[('scalar', scaler), ('classifier', classifier)])
acc_score = cross_val_score(pipe,X, Y_cls, cv=5).mean()
print(f"model {classifier} score: {acc_score}")
classifiers = [
DecisionTreeClassifier(),
RandomForestClassifier(),
AdaBoostClassifier(),
GradientBoostingClassifier()]
for classifier in classifiers:
acc_score = cross_val_score(classifier,X, Y_cls, cv=5).mean()
print(f"model {classifier} score: {acc_score}")
model KNeighborsClassifier() score: 0.68362520027338 model SVC(C=0.025, probability=True) score: 0.3604920842996874 model LogisticRegression(C=0.01, max_iter=1000, multi_class='ovr') score: 0.46426114528363194 model DecisionTreeClassifier() score: 0.7314880172095055 model RandomForestClassifier() score: 0.7930971507960518 model AdaBoostClassifier() score: 0.35865461104948854 model GradientBoostingClassifier() score: 0.740975653479435

possible_k= range(1,15)
for k in possible_k:
pipe = Pipeline([('preprocessing', MinMaxScaler()),
('classifier',KNeighborsClassifier(n_neighbors= k,weights = 'distance',metric="euclidean" ))])
pipe.fit(X_train,y_train)
y_pred=pipe.predict(X_test)
scores=accuracy_score(y_test,y_pred)
print (f"{k}--- Accuracy Scores :", scores)
1--- Accuracy Scores : 0.7253787878787878 2--- Accuracy Scores : 0.7234848484848485 3--- Accuracy Scores : 0.7462121212121212 4--- Accuracy Scores : 0.7443181818181818 5--- Accuracy Scores : 0.7329545454545454 6--- Accuracy Scores : 0.7367424242424242 7--- Accuracy Scores : 0.7386363636363636 8--- Accuracy Scores : 0.7329545454545454 9--- Accuracy Scores : 0.740530303030303 10--- Accuracy Scores : 0.7291666666666666 11--- Accuracy Scores : 0.7234848484848485 12--- Accuracy Scores : 0.7234848484848485 13--- Accuracy Scores : 0.7178030303030303 14--- Accuracy Scores : 0.7178030303030303
k = 4 will perform the best for this model
pipe = Pipeline([('preprocessing', MinMaxScaler()), ('classifier',KNeighborsClassifier(n_neighbors = 4,
weights = 'distance',metric="euclidean" ))])
pipe.fit(X_train, y_train)
pipe_pred = pipe.predict(X_test)
print(confusion_matrix(pipe_pred, y_test))
scores = cross_val_score(pipe, X_train, y_train, cv = KFold(n_splits = 5))
print('Mean score: {:.2f}'.format(scores.mean()))
print('-----------------------------------------------------')
print(classification_report(y_test, pipe_pred))
[[60 17 4 4 2 0 0]
[ 2 31 11 2 4 0 0]
[ 2 6 42 9 6 0 0]
[ 1 7 6 42 8 1 0]
[ 1 7 9 6 70 3 1]
[ 0 3 2 4 4 58 0]
[ 1 0 2 0 0 0 90]]
Mean score: 0.71
-----------------------------------------------------
precision recall f1-score support
0 0.69 0.90 0.78 67
1 0.62 0.44 0.51 71
2 0.65 0.55 0.60 76
3 0.65 0.63 0.64 67
4 0.72 0.74 0.73 94
5 0.82 0.94 0.87 62
6 0.97 0.99 0.98 91
accuracy 0.74 528
macro avg 0.73 0.74 0.73 528
weighted avg 0.74 0.74 0.74 528
params = { 'criterion': ['gini', 'entropy'],
'max_depth': [5,10,15,20, 25, 30]}
grid = GridSearchCV(DecisionTreeClassifier(), param_grid=params, n_jobs=-1, cv=5)
grid.fit(X_train, y_train)
GridSearchCV(cv=5, estimator=DecisionTreeClassifier(), n_jobs=-1,
param_grid={'criterion': ['gini', 'entropy'],
'max_depth': [5, 10, 15, 20, 25, 30]})
print('Best params: {}'.format(grid.best_params_))
print("Best cross-validation score: {:.2f}".format(grid.best_score_))
Best params: {'criterion': 'gini', 'max_depth': 15}
Best cross-validation score: 0.73
dt = DecisionTreeClassifier(criterion = 'gini', max_depth = 30)
dt.fit(X_train, y_train)
y_pred = dt.predict(X_test)
print(confusion_matrix(y_pred, y_test))
print('-----------------------------------------------------')
print(classification_report(y_test, y_pred))
[[60 12 1 1 1 1 0]
[ 6 34 13 3 9 0 0]
[ 0 4 44 6 1 0 0]
[ 0 8 8 49 11 5 0]
[ 0 10 5 4 70 4 0]
[ 1 3 5 4 2 52 0]
[ 0 0 0 0 0 0 91]]
-----------------------------------------------------
precision recall f1-score support
0 0.79 0.90 0.84 67
1 0.52 0.48 0.50 71
2 0.80 0.58 0.67 76
3 0.60 0.73 0.66 67
4 0.75 0.74 0.75 94
5 0.78 0.84 0.81 62
6 1.00 1.00 1.00 91
accuracy 0.76 528
macro avg 0.75 0.75 0.75 528
weighted avg 0.76 0.76 0.75 528
features = X_names
importances = dt.feature_importances_
indices = np.argsort(importances)
plt.title('Feature Importances')
plt.barh(range(len(indices)), importances[indices], color='b', align='center')
plt.yticks(range(len(indices)), [features[i] for i in indices])
plt.xlabel('Relative Importance')
plt.show()
rdf = RandomForestClassifier(random_state=42)
rdf.fit(X_train, y_train)
print(rdf.score(X_train, y_train))
print(rdf.score(X_test, y_test))
0.9962097283638661 0.8106060606060606
param_grid = {
'max_depth': [5,10,15,20],
'n_estimators': [200, 300]}
grid = GridSearchCV(rdf, param_grid=param_grid, n_jobs=-1, cv=5)
grid.fit(X_train, y_train)
GridSearchCV(cv=5, estimator=RandomForestClassifier(random_state=42), n_jobs=-1,
param_grid={'max_depth': [5, 10, 15, 20],
'n_estimators': [200, 300]})
print('Best params: {}'.format(grid.best_params_))
print("Best cross-validation score: {:.2f}".format(grid.best_score_))
Best params: {'max_depth': 15, 'n_estimators': 300}
Best cross-validation score: 0.80
rdf = RandomForestClassifier(random_state=42, max_depth = 20, n_estimators = 300)
rdf.fit(X_train, y_train)
y_pred = rdf.predict(X_test)
print(confusion_matrix(y_pred, y_test))
print('Accuracy on test set: {:.2f}'.format(accuracy_score(y_pred, y_test)))
print('-----------------------------------------------------')
print(classification_report(y_test, y_pred))
[[64 9 1 3 1 0 0]
[ 2 47 9 1 5 1 0]
[ 1 0 50 4 2 0 0]
[ 0 7 5 47 8 1 0]
[ 0 6 8 4 75 1 0]
[ 0 2 3 8 3 59 0]
[ 0 0 0 0 0 0 91]]
Accuracy on test set: 0.82
-----------------------------------------------------
precision recall f1-score support
0 0.82 0.96 0.88 67
1 0.72 0.66 0.69 71
2 0.88 0.66 0.75 76
3 0.69 0.70 0.70 67
4 0.80 0.80 0.80 94
5 0.79 0.95 0.86 62
6 1.00 1.00 1.00 91
accuracy 0.82 528
macro avg 0.81 0.82 0.81 528
weighted avg 0.82 0.82 0.82 528
features = X_names
importances = rdf.feature_importances_
indices = np.argsort(importances)
plt.title('Random Forest Feature Importances')
plt.barh(range(len(indices)), importances[indices], color='b', align='center')
plt.yticks(range(len(indices)), [features[i] for i in indices])
plt.xlabel('Relative Importance')
plt.show()
In comparison to the feature importances of Decision Tree:

grbt = GradientBoostingClassifier(random_state = 0)
param_grid = {'learning_rate':[0.1,0.01,0.001],
'n_estimators':[200, 300],
'max_depth':[2,3,4,5]}
grid = GridSearchCV(grbt, param_grid=param_grid, n_jobs=-1, cv=5)
grid.fit(X_train, y_train)
GridSearchCV(cv=5, estimator=GradientBoostingClassifier(random_state=0),
n_jobs=-1,
param_grid={'learning_rate': [0.1, 0.01, 0.001],
'max_depth': [2, 3, 4, 5],
'n_estimators': [200, 300]})
print('Best params: {}'.format(grid.best_params_))
print("Best cross-validation score: {:.2f}".format(grid.best_score_))
Best params: {'learning_rate': 0.1, 'max_depth': 5, 'n_estimators': 200}
Best cross-validation score: 0.77
grdt = GradientBoostingClassifier(learning_rate = 0.1, max_depth = 4, n_estimators = 200)
grdt.fit(X_train, y_train)
y_pred = grdt.predict(X_test)
print(confusion_matrix(y_pred, y_test))
print('Accuracy on test set: {:.2f}'.format(accuracy_score(y_pred, y_test)))
print('-----------------------------------------------------')
print(classification_report(y_test, y_pred))
[[63 7 0 1 2 0 0]
[ 2 48 6 2 5 1 0]
[ 2 3 51 5 5 1 0]
[ 0 6 9 44 8 4 0]
[ 0 5 8 6 70 1 0]
[ 0 2 2 9 3 55 0]
[ 0 0 0 0 1 0 91]]
Accuracy on test set: 0.80
-----------------------------------------------------
precision recall f1-score support
0 0.86 0.94 0.90 67
1 0.75 0.68 0.71 71
2 0.76 0.67 0.71 76
3 0.62 0.66 0.64 67
4 0.78 0.74 0.76 94
5 0.77 0.89 0.83 62
6 0.99 1.00 0.99 91
accuracy 0.80 528
macro avg 0.79 0.80 0.79 528
weighted avg 0.80 0.80 0.80 528
strat = StratifiedShuffleSplit(n_splits=1, test_size=0.2, random_state=5)
for train_index, test_index in strat.split(X, Y_cls):
Xs_train, Xs_test = X[train_index], X[test_index]
ys_train, ys_test = Y_cls[train_index], Y_cls[test_index]
Xs_train.shape
(1688, 17)
label = 100
pipe = Pipeline([("scaler", MinMaxScaler()),
("logreg", LogisticRegression(C=10, max_iter = 2000, penalty = 'l2'))])
pipe.fit(Xs_train[:label],ys_train[:label])
print('Score on test set: {:.2f}'.format(pipe.score(Xs_test, ys_test)))
Score on test set: 0.52
With only 100 labels, the score is low with 52%.
In this part, the representative sample need to be found using Kmeans. We used inertia score to find the best k.
inertia = []
for k in range(5, 20):
kmeans = KMeans(n_clusters=k, random_state=5)
kmeans.fit(Xs_train)
inertia.append(kmeans.inertia_)
k = np.argmin(inertia)
k
14
k=14
kmeans=KMeans(n_clusters=k, random_state=42)
X_dist=kmeans.fit_transform(Xs_train)
representative_idx=np.argmin(X_dist,axis=0)
X_rep=Xs_train[representative_idx]
X_dist
array([[ 2.12029336, 13.62029027, 4.03328771, ..., 1.2139064 ,
4.31600712, 6.7034686 ],
[ 3.73100067, 18.18986614, 2.11524454, ..., 5.45436035,
2.8007482 , 3.05756269],
[ 5.1947425 , 20.08125885, 2.85049387, ..., 6.99525905,
3.66295779, 2.05474889],
...,
[ 2.11128352, 16.66964963, 1.55416262, ..., 3.89546815,
2.56471019, 3.73741781],
[ 2.58343238, 14.155144 , 3.80396231, ..., 2.16108283,
4.15544143, 6.45122093],
[ 1.20374977, 15.10964254, 2.81962791, ..., 2.64332002,
3.25465866, 5.1784327 ]])
X_rep.shape
(14, 17)
y_rep=ys_train[representative_idx]
y_rep
array([2, 4, 6, 5, 3, 6, 4, 3, 3, 4, 5, 5, 2, 4])
pipe = Pipeline([("scaler", MinMaxScaler()),
("logreg", LogisticRegression(C=10, max_iter = 2000, penalty = 'l2'))])
pipe.fit(X_rep, y_rep)
print('Score on test set: {:.4f}'.format(pipe.score(Xs_test, ys_test)))
Score on test set: 0.3073
y_train_label=np.empty(len(Xs_train))
for i in range(k):
y_train_label[kmeans.labels_==i]=y_rep[i]
pipe = Pipeline([("scaler", MinMaxScaler()),
("logreg", LogisticRegression(C=10, max_iter = 2000, penalty = 'l2'))])
pipe.fit(Xs_train,y_train_label)
print('Score on test set: {:.4f}'.format(pipe.score(Xs_test, ys_test)))
Score on test set: 0.3593
percentile = 20
X_cluster_distance=X_dist[np.arange(len(Xs_train)),kmeans.labels_]
for i in range(14):
intra_cluster=(kmeans.labels_==i)
cluster_dist=X_cluster_distance[intra_cluster]
distance=np.percentile(cluster_dist,percentile)
above_distance=(X_cluster_distance>distance)
X_cluster_distance[intra_cluster& above_distance]=-1
partial_select=(X_cluster_distance!=-1)
X_train_selected=Xs_train[partial_select]
y_train_selected=ys_train[partial_select]
pipe = Pipeline([("scaler", MinMaxScaler()),
("logreg", LogisticRegression(C=10, max_iter = 2000, penalty = 'l2'))])
pipe.fit(X_train_selected,y_train_selected)
print('Score on test set: {:.4f}'.format(pipe.score(Xs_test, ys_test)))
Score on test set: 0.5130
In this part, we aims to classify to around balanced 7 groups as original dataset have balanced target variable.
X_ca=X[:,1:]
X_ca_names=X_names[1:]
chi2,pval=feature_selection.chi2(X_ca,Y_cls)
pval<0.05
array([ True, True, True, True, True, True, True, True, True,
True, True, True, True, True, True, True])
chi2
array([ 61.1691452 , 34.62941057, 23.80971639, 78.57800744,
30.96904092, 324.97835865, 113.43537784, 27.08129767,
31.46797672, 117.42925431, 76.27328869, 67.67752222,
14.98734238, 19.31647735, 37.76144964, 99.25306084])
varThres=feature_selection.VarianceThreshold(threshold=0.01)
X_select=varThres.fit_transform(X)
varThres.variances_
array([40.25223644, 0.3407838 , 0.65527102, 0.4739672 , 0.80147189,
0.45407232, 0.24996494, 0.14911628, 0.10258911, 0.02040876,
0.043408 , 0.21942899, 0.26561237, 0.00330497, 0.00518365,
0.18826741, 0.02582399])
X_select.shape, X.shape
((2111, 15), (2111, 17))
scale=MinMaxScaler()
X_scale=scale.fit_transform(X)
pca=PCA(n_components=0.99,random_state=40)
full_pca=pca.fit_transform(X_scale)
full_recover=pca.inverse_transform(full_pca)
MSE_score = ((X_scale-full_recover)**2).sum(axis=1)
MSE_score.sort()
plt.plot(MSE_score)
plt.axvline(2080,c='r')
thredhold=MSE_score[2080]
thredhold
MSE_score = ((X_scale-full_recover)**2).sum(axis=1)
full_noout=full_pca[np.argwhere(MSE_score<thredhold).flatten()]
full_noout.shape
(2080, 15)
As discussed in the EDA part, we do not have many outliners in our data. That is why the graph show at the end only few points MSE are high. We removed 31 outliner points.
tsne=TSNE(n_components=2,random_state=40)
x_reduce=tsne.fit_transform(X)
plt.figure(figsize=(10,10))
plt.subplot(221)
plt.scatter(x_reduce[:,0],x_reduce[:,1],c=Y_cls,cmap="jet")
plt.title('TSNE all original features')
tsne=TSNE(n_components=2,random_state=40)
x_reduce=tsne.fit_transform(X_select)
plt.subplot(222)
plt.scatter(x_reduce[:,0],x_reduce[:,1],c=Y_cls,cmap="jet")
plt.title('TSNE selected features')
tsne=TSNE(n_components=2,random_state=40)
x_reduce=tsne.fit_transform(full_pca)
plt.subplot(223)
plt.scatter(x_reduce[:,0],x_reduce[:,1],c=Y_cls,cmap="jet")
plt.title('TSNE_all features scaled & pca')
tsne=TSNE(n_components=2,random_state=40)
x_reduce=tsne.fit_transform(full_noout)
plt.subplot(224)
plt.scatter(x_reduce[:,0],x_reduce[:,1],c=Y_cls[np.argwhere(MSE_score<thredhold).flatten()],cmap="jet")
plt.title('TSNE_all features scaled & pca & remove outliners')
Text(0.5, 1.0, 'TSNE_all features scaled & pca & remove outliners')
tsne=TSNE(n_components=2,random_state=40)
x_reduce=tsne.fit_transform(X_scale)
plt.figure(figsize=(10,10))
plt.plot(x_reduce[:, 0][Y_cls==0], x_reduce[:, 1][Y_cls==0], 'o',
markeredgecolor='k', markersize=8,label='underweight')
plt.plot(x_reduce[:, 0][Y_cls==1], x_reduce[:, 1][Y_cls==1], 'o',
markeredgecolor='k', markersize=8,label='normal')
plt.plot(x_reduce[:, 0][Y_cls==2], x_reduce[:, 1][Y_cls==2], 'o',
markeredgecolor='k', markersize=8,label='overweight 1')
plt.plot(x_reduce[:, 0][Y_cls==3], x_reduce[:, 1][Y_cls==3], 'o',
markeredgecolor='k', markersize=8,label='overweight 2')
plt.plot(x_reduce[:, 0][Y_cls==4], x_reduce[:, 1][Y_cls==4], 'o',
markeredgecolor='k', markersize=8, label='obesity 1')
plt.plot(x_reduce[:, 0][Y_cls==5], x_reduce[:, 1][Y_cls==5], 'o',
markeredgecolor='k', markersize=8, label='obesity 2')
plt.plot(x_reduce[:, 0][Y_cls==6], x_reduce[:, 1][Y_cls==6], 'o',
markeredgecolor='k', markersize=8, label='obesity 3')
plt.legend()
<matplotlib.legend.Legend at 0x7fda399ae550>
n_components = np.arange(1, 10, 1)
cova=['full', 'tied', 'diag', 'spherical']
plt.figure(figsize=(10,10))
for i in range(1,5):
models = [GaussianMixture(n, covariance_type=cova[i-1], random_state=0)
for n in n_components]
aics = [model.fit(X).aic(X) for model in models]
bics = [model.fit(X).bic(X) for model in models]
plt.subplot(220+i)
plt.plot(n_components, aics, label='AIC');
plt.plot(n_components, bics,label='BIC');
plt.title(cova[i-1])
plt.legend()
gm=GaussianMixture(7, covariance_type='full', random_state=0)
gm.fit(X)
gm.converged_
True
for i in np.unique(gm.predict(X)):
print(f'label {i}: {X[gm.predict(X)==i].shape[0]} times {np.unique(X[gm.predict(X)==i],axis=0).shape[0]} unique rows')
label 0: 641 times 539 unique rows label 1: 50 times 50 unique rows label 2: 134 times 132 unique rows label 3: 20 times 20 unique rows label 4: 428 times 425 unique rows label 5: 186 times 182 unique rows label 6: 652 times 613 unique rows
tsne=TSNE(n_components=2,random_state=40)
x_reduce=tsne.fit_transform(X)
plt.figure(figsize=(10,10))
plt.subplot(221)
plt.scatter(x_reduce[:,0],x_reduce[:,1],c=gm.predict(X),cmap="jet")
<matplotlib.collections.PathCollection at 0x7fda3981d590>
n_components = np.arange(1, 10, 1)
cova=['full', 'tied', 'diag', 'spherical']
plt.figure(figsize=(10,10))
for i in range(1,5):
models = [GaussianMixture(n, covariance_type=cova[i-1], random_state=0)
for n in n_components]
aics = [model.fit(X_scale).aic(X_scale) for model in models]
bics = [model.fit(X_scale).bic(X_scale) for model in models]
plt.subplot(220+i)
plt.plot(n_components, aics, label='AIC');
plt.plot(n_components, bics,label='BIC');
plt.title(cova[i-1])
plt.legend()
gm1=GaussianMixture(7, covariance_type='diag', random_state=0)
gm1.fit(X_scale)
y_clusters=gm.predict(X_scale)
np.unique(gm.predict(X_scale))
gm.converged_
True
for i in np.unique(gm1.predict(X_scale)):
print(f'label {i}: {X_scale[gm1.predict(X_scale)==i].shape[0]} times {np.unique(X_scale[gm1.predict(X_scale)==i],axis=0).shape[0]} unique rows')
label 0: 615 times 587 unique rows label 1: 308 times 304 unique rows label 2: 86 times 86 unique rows label 3: 234 times 212 unique rows label 4: 163 times 163 unique rows label 5: 136 times 134 unique rows label 6: 569 times 475 unique rows
the best option =)
tsne=TSNE(n_components=2,random_state=40)
x_reduce=tsne.fit_transform(X)
tsne1=TSNE(n_components=2,random_state=40)
x_reduce1=tsne.fit_transform(X)
#--------
plt.figure(figsize=(20,10))
plt.subplot(121)
plt.scatter(x_reduce[:,0],x_reduce[:,1],c=gm1.predict(X_scale),cmap="jet")
plt.title('TSNE_all features scaled GAUSSIAN MIXTURE CLUSTERS labels')
plt.subplot(122)
plt.scatter(x_reduce1[:,0],x_reduce1[:,1],c=Y_cls,cmap="jet")
plt.title('TSNE all original features')
Text(0.5, 1.0, 'TSNE all original features')
bgm=BayesianGaussianMixture(n_components=10,n_init=10,random_state=42)
bgm.fit(X)
BayesianGaussianMixture(n_components=10, n_init=10, random_state=42)
mask=np.round(bgm.weights_,2)>0
labels=np.unique(bgm.predict(X))[mask] # chosen clusters' labels.
for i in labels:
print(f'label {i}: {X[bgm.predict(X)==i].shape[0]} times {np.unique(X[bgm.predict(X)==i],axis=0).shape[0]} unique rows')
label 0: 641 times 539 unique rows label 2: 12 times 11 unique rows label 3: 732 times 713 unique rows label 4: 32 times 32 unique rows label 5: 29 times 29 unique rows label 6: 457 times 431 unique rows label 8: 82 times 81 unique rows label 9: 114 times 113 unique rows
kmeans=KMeans() # baseline k=8
all_dis=kmeans.fit_transform(X) # on selected features
kmeans.inertia_
9800.120094979682
I=[]
for i in np.arange(1,100,10):
kmeans=KMeans(n_clusters=i) # baseline k=8
kmeans.fit(X)
I.append(kmeans.inertia_)
plt.plot(np.arange(1,100,10),I)
plt.axvline(10,c='r')
<matplotlib.lines.Line2D at 0x7fda20b9e6d0>
kmeans=KMeans(n_clusters=7)
all_dis=kmeans.fit_transform(X) # on selected features
print(silhouette_score(X,kmeans.labels_))
0.25920316990721515
for i in np.unique(kmeans.labels_):
print(f'label {i}: {X[kmeans.labels_==i].shape[0]} times {np.unique(X[kmeans.labels_==i],axis=0).shape[0]} unique rows')
label 0: 387 times 376 unique rows label 1: 150 times 150 unique rows label 2: 252 times 252 unique rows label 3: 361 times 276 unique rows label 4: 14 times 14 unique rows label 5: 466 times 436 unique rows label 6: 481 times 457 unique rows
tsne=TSNE(n_components=2,random_state=40)
x_reduce=tsne.fit_transform(X)
plt.figure(figsize=(20,10))
plt.subplot(121)
plt.scatter(x_reduce[:,0],x_reduce[:,1],c=kmeans.predict(X),cmap="jet")
plt.title('TSNE_all features scaled K-MEAN CLUSTERS labels')
plt.subplot(122)
plt.scatter(x_reduce1[:,0],x_reduce1[:,1],c=Y_cls,cmap="jet")
plt.title('TSNE all original features')
Text(0.5, 1.0, 'TSNE all original features')
print('GAUSSIAN MIXTURE ON ORIGINAL FEATURES')
for i in np.unique(gm.predict(X)):
print(f'label {i}: {X[gm.predict(X)==i].shape[0]} times {np.unique(X[gm.predict(X)==i],axis=0).shape[0]} unique rows')
print('-----------------------------------------------------------------------------------------')
print('GAUSSIAN MIXTURE ON SCALED FEATURES')
for i in np.unique(gm1.predict(X_scale)):
print(f'label {i}: {X_scale[gm1.predict(X_scale)==i].shape[0]} times {np.unique(X_scale[gm1.predict(X_scale)==i],axis=0).shape[0]} unique rows')
print('-----------------------------------------------------------------------------------------')
print('KMEANS ON ORIGINAL FEATURES')
for i in np.unique(kmeans.labels_):
print(f'label {i}: {X[kmeans.labels_==i].shape[0]} times {np.unique(X[kmeans.labels_==i],axis=0).shape[0]} unique rows')
print('-----------------------------------------------------------------------------------------')
print('BAYESSIAN GAUSSIAN MIXTURE ON ORIGINAL FEATURES')
for i in labels:
print(f'label {i}: {X[bgm.predict(X)==i].shape[0]} times {np.unique(X[bgm.predict(X)==i],axis=0).shape[0]} unique rows')
GAUSSIAN MIXTURE ON ORIGINAL FEATURES label 0: 641 times 539 unique rows label 1: 50 times 50 unique rows label 2: 134 times 132 unique rows label 3: 20 times 20 unique rows label 4: 428 times 425 unique rows label 5: 186 times 182 unique rows label 6: 652 times 613 unique rows ----------------------------------------------------------------------------------------- GAUSSIAN MIXTURE ON SCALED FEATURES label 0: 615 times 587 unique rows label 1: 308 times 304 unique rows label 2: 86 times 86 unique rows label 3: 234 times 212 unique rows label 4: 163 times 163 unique rows label 5: 136 times 134 unique rows label 6: 569 times 475 unique rows ----------------------------------------------------------------------------------------- KMEANS ON ORIGINAL FEATURES label 0: 387 times 376 unique rows label 1: 150 times 150 unique rows label 2: 252 times 252 unique rows label 3: 361 times 276 unique rows label 4: 14 times 14 unique rows label 5: 466 times 436 unique rows label 6: 481 times 457 unique rows ----------------------------------------------------------------------------------------- BAYESSIAN GAUSSIAN MIXTURE ON ORIGINAL FEATURES label 0: 641 times 539 unique rows label 2: 12 times 11 unique rows label 3: 732 times 713 unique rows label 4: 32 times 32 unique rows label 5: 29 times 29 unique rows label 6: 457 times 431 unique rows label 8: 82 times 81 unique rows label 9: 114 times 113 unique rows
Remember our goals at the begining of the unsupervised learning, we try to find clustering method that give balanced labels that are close to 7 clusters. These crietia can be judged via total number of labels, number of times (= number of observations in a cluster). Besides, the homogeneity level within a cluster is consider important, which will be measure by looking at the unique rows in a label.
Basing on above mentioned metrics and looking at the result showed above, we can conclude that GAUSSIAN MIXTURE ON SCALED FEATURES is the best method.
The plot in each part comparing between data with clustering label vs data with original labels also lead to the same conclusion. However, in unsupervised learning, we do not know the orginal labels.
classifiers = [
KNeighborsClassifier(n_neighbors = 5),
SVC(kernel="rbf", C=0.025, probability=True),
LogisticRegression(C=0.01, max_iter = 1000, penalty = 'l2',multi_class='ovr')]
scaler = MinMaxScaler()
for classifier in classifiers:
pipe = Pipeline(steps=[('scalar', scaler), ('classifier', classifier)])
acc_score = cross_val_score(pipe,X, y_clusters, cv=5).mean()
print(f"model {classifier} score: {acc_score}")
classifiers = [
DecisionTreeClassifier(),
RandomForestClassifier(),
AdaBoostClassifier(),
GradientBoostingClassifier()]
for classifier in classifiers:
acc_score = cross_val_score(classifier,X, y_clusters, cv=5).mean()
print(f"model {classifier} score: {acc_score}")
model KNeighborsClassifier() score: 0.9635339988571812 model SVC(C=0.025, probability=True) score: 0.9104702362945784 model LogisticRegression(C=0.01, max_iter=1000, multi_class='ovr') score: 0.8550580932853796 model DecisionTreeClassifier() score: 0.9976325725745913 model RandomForestClassifier() score: 0.9914792780074618 model AdaBoostClassifier() score: 0.9663719987003239 model GradientBoostingClassifier() score: 0.9990532531119403
Supervised learning - regression
To understand the overall algorithms' suitability for our data we used the default settings of the Linear regression, RANSAC, Gradient descent, Supporting vector machine ("SVM"), Decision tree and Random forest models and selected SVM, Decision tree and Random forest for further parameter tuning as these achieved the best scores. The best performance could be achieved with the Random forest model which significantly outperformed other models and reached the 86% accuracy without overfitting on the training set.
Supervised learning - classification
We used Kneighbor Classifier, SVC, Logistic Regession, Decision Tree, Random Forest, AdaBoost Classifier, and GradientBoosting to compare the accuracy score without tunning for the model selection. And with the accuracy score higher than 0.7, I chose Kneighbor Classifier, Decision Tree, Random Forest, and Gradient Boosting to continue. After feature scaling and parameters tuning, Random Forsest give the best result with accuracy score reached 84% and also a balanced f1_score between labels. Therefore, Random Forest will be selected among others to be the model prediction for the Obesity Level classification task.
Semi-supervised learning
We choose Logistic Regression as the model to work on. With the limited 100 labeled data, the accuracy score is 52%. After finding the representative sample using Kmeans and giving the labels to other instances, the score decreases to 35%. To improve the score, propagating the label to the 50 percentile closest to the centroid is used and make the improvement with the accuracy score is 57%. However, it is still need further improvement on both Kmeans and model selection as the score is still lower than expected.
Unsupervised learning
We try to cluster around 7 balanced groups. We visualize our data using TSNE basing on original data, selected data from feature engineering, scaled and dimension deduction data, removed outliner data. First, we see that using feature engineer or remove outliners in this case do not bring significant impact, and secondly to identify relatively suitable clustering methods: Gaussian Mixture, Bayes Gaussian Mixture, and K-Means. After tuning parameters, Gaussian Mixture with scaled data input is the best option. The best output of clustering works well with SVC and Decision Tree, Random Forest, Gradient Boosting.
